1.高效節能
采用先進流體技術，獨特設計，高精度加工，提高效率，降低能耗，減少用戶使用成本
2.運行穩定
采用新型水力模型，高精密度生產設備，運行始終保持穩定。
3.壽命長久
材質選擇要求高，結構合理，密封結構設計獨特，延長了水泵使用壽命。
4.維護率低
易損件采用進口產品，經久耐用，減少維護次數，降低了用戶維護成本。
5.使用廣泛
產品已投入使用到發電、供水、冶煉、采礦、環保、造紙等多個行業。
| WQP潛水排污泵型號 | 流量 (m3/h) |
揚程 (M) |
功率 (kw) |
口徑 mm |
轉速 (r/min) |
效率 (%) |
使用揚程范圍 |
| 25WQ7-8-0.75P | 7 | 8 | 0.55 | 25 | 2900 | 45 | 3-8 |
| 25WQ8-22-1.1P | 8 | 22 | 1.1 | 25 | 2900 | 45 | 10-22 |
| 32WQ8-12-0.75P | 8 | 12 | 0.75 | 32 | 2900 | 48 | 7-12 |
| 32WQ12-15-1.1P | 12 | 15 | 1.1 | 32 | 2900 | 45 | 7-15 |
| 40WQ15-15-1.5P | 15 | 15 | 1.5 | 40 | 2900 | 48 | 6-15 |
| 40WQ15-30-2.2P | 15 | 30 | 2.2 | 40 | 2900 | 54 | 15-30 |
| 50WQ20-7-0.75P | 20 | 7 | 0.75 | 50 | 2900 | 51 | 3-7 |
| 50WQ10-10-0.75P | 10 | 10 | 0.75 | 50 | 2900 | 52 | 4-10 |
| 50WQ20-15-1.5P | 20 | 15 | 1.5 | 50 | 2900 | 53 | 6-15 |
| 50WQ15-25-2.2P | 15 | 25 | 2.2 | 50 | 2900 | 54 | 10-25 |
| 50WQ18-30-3P | 18 | 30 | 3 | 50 | 2900 | 55 | 15-30 |
| 50WQ40-15-4P | 40 | 15 | 4 | 50 | 2900 | 55 | 8-15 |
| 50WQ25-32-5.5P | 25 | 32 | 5.5 | 50 | 2900 | 55 | 17-32 |
| 50WQ20-40-7.5P | 50 | 20 | 7.5 | 50 | 2900 | 58 | 20-40 |
| 65WQ25-15-2.2P | 25 | 15 | 2.2 | 65 | 2900 | 50 | 6-15 |
| 65WQ37-13-3P | 37 | 13 | 3 | 65 | 2900 | 57 | 6-13 |
| 65WQ25-30-4P | 25 | 30 | 4 | 65 | 2900 | 61 | 15-30 |
| 65WQ30-40-7.5P | 30 | 40 | 7.5 | 65 | 2900 | 56 | 20-40 |
| 65WQ35-50-11P | 35 | 50 | 11 | 65 | 2900 | 45 | 35-50 |
| 65WQ35-60-15P | 35 | 60 | 15 | 65 | 2900 | 65 | 40-60 |
| 80WQ60-13-5.5P | 60 | 13 | 5.5 | 80 | 2900 | 67 | 7-13 |
| 80WQ40-7-2.2P | 40 | 7 | 2.2 | 80 | 1450 | 59 | 3-7 |
| 80WQ43-13-3P | 43 | 13 | 3 | 80 | 2900 | 70 | 5-13 |
| 80WQ40-15-4P | 40 | 15 | 4 | 80 | 2900 | 61 | 6-15 |
| 80WQ65-25-7.5P | 65 | 25 | 7.5 | 80 | 2900 | 63 | 12-25 |
| 100WQ80-10-4P | 100 | 10 | 4 | 100 | 1450 | 65 | 4-10 |
| 100WQ100-15-7.5P | 100 | 15 | 7.5 | 100 | 1450 | 68 | 8-15 |
| 100WQ110-10-5.5P | 110 | 10 | 5.5 | 100 | 1450 | 66 | 5-10 |
| 100WQ80-20-7.5P | 80 | 20 | 7.5 | 100 | 1450 | 65 | 10-20 |
| 100WQ100-25-11P | 100 | 25 | 11 | 100 | 1450 | 70 | 10-25 |
| 100WQ100-30-15P | 100 | 30 | 15 | 100 | 1450 | 65 | 12-30 |
| 100WQ100-35-18.5P | 100 | 35 | 18.5 | 100 | 1450 | 68 | 15-35 |
| 125WQ130-15-11P | 130 | 15 | 11 | 125 | 1450 | 72 | 7-15 |
| 125WQ130-20-15P | 130 | 20 | 15 | 125 | 1450 | 75 | 10-20 |
| 150WQ145-9-7.5P | 145 | 9 | 7.5 | 150 | 1450 | 76 | 4-9 |
| 150WQ180-15-15P | 180 | 15 | 15 | 150 | 1450 | 69 | 5-15 |
| 150WQ180-20-18.5P | 180 | 20 | 18.5 | 150 | 1450 | 72 | 8-20 |
| 150WQ180-25-22P | 180 | 25 | 22 | 150 | 1450 | 78 | 12-25 |
| 150WQ130-30-22P | 130 | 30 | 22 | 150 | 1450 | 78 | 15-30 |
| 150WQ180-30-30P | 180 | 30 | 30 | 150 | 1450 | 78 | 15-30 |
| 150WQ200-30-37P | 200 | 30 | 37 | 150 | 1450 | 73 | 13-30 |
| 200WQ300-7-11P | 300 | 7 | 11 | 200 | 980 | 66 | 3-7 |
| 200WQ250-11-15P | 250 | 11 | 15 | 200 | 1450 | 64 | 4-11 |
| 200WQ250-15-18.5P | 250 | 15 | 18.5 | 200 | 1450 | 73 | 7-15 |
| 200WQ400-10-22P | 400 | 10 | 22 | 200 | 1450 | 75 | 5-10 |
| 200WQ400-13-30P | 400 | 13 | 30 | 200 | 1450 | 76 | 6-13 |
| 200WQ300-15-22P | 300 | 15 | 22 | 200 | 1450 | 76 | 8-15 |
| 200WQ250-22-30P | 250 | 22 | 30 | 200 | 1450 | 71 | 12-22 |
| 200WQ350-25-37P | 350 | 25 | 37 | 200 | 1450 | 71 | 10-25 |
| 200WQ400-30-45P | 400 | 30 | 45 | 200 | 1450 | 74 | 13-30 |
| 250WQ600-9-30P | 600 | 9 | 30 | 250 | 980 | 78 | 3-9 |
| 250WQ600-12-37P | 600 | 12 | 37 | 250 | 1450 | 76 | 5-12 |
| 250WQ600-15-45P | 600 | 15 | 45 | 250 | 1450 | 73 | 6-15 |
| 250WQ600-20-55P | 600 | 20 | 55 | 250 | 1450 | 73 | 8-20 |
| 250WQ600-25-75P | 600 | 25 | 75 | 250 | 1450 | 71 | 12-25 |
| 300WQ800-12-45 | 800 | 12 | 45 | 300 | 980 | 74 | 5-12 |
| 300WQ480-15-45P | 480 | 15 | 45 | 300 | 1450 | 66 | 7-15 |
| 300WQ800-15-55P | 800 | 15 | 55 | 300 | 1450 | 73 | 8-15 |
| 300WQ600-20-55P | 600 | 20 | 55 | 300 | 1450 | 73 | 10-20 |
| 300WQ800-20-75P | 800 | 20 | 75 | 300 | 1450 | 75 | 11-20 |
| 300WQ950-20-90P | 950 | 20 | 90 | 300 | 1450 | 76 | 11-20 |
| 300WQ1000-25-110P | 1000 | 25 | 110 | 300 | 1450 | 76 | 12-25 |
| 300WQ1100-10-55P | 1100 | 10 | 55 | 300 | 1450 | 73 | 4-10 |
| 350WQ1500-15-90P | 1500 | 15 | 90 | 350 | 740 | 87 | 6-15 |
| 350WQ1200-18-90P | 1200 | 18 | 90 | 350 | 980 | 85 | 8-18 |
